Heavy Duty T45 DTH Drill Bits For Hammer Drill With Double Gauge Face

Heavy Duty T45 DTH Drill Bits For Hammer Drill With Double Gauge Face

  • Heavy Duty T45 DTH Drill Bits For Hammer Drill With Double Gauge Face
Heavy Duty T45 DTH Drill Bits For Hammer Drill With Double Gauge Face
Product Details:
Place of Origin: Hunan, China (Mainland)
Brand Name: New Diamond
Certification: ISO9001:2008
Model Number: T45
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: Carton packaging and wooden box packing
Delivery Time: 5-8 work days
Payment Terms: L/C, T/T, Western Union
Supply Ability: According to order quantity
Contact Now
Detailed Product Description
Type: Drill Bit Carbide Shape: Spherical, Ballistic, Ogive, Parabolic, Flat
Bit Face: Center Drop/Flat/convex/concave/double Gauge Face Bits Color: Required
Button Shape: Spherical/Ballistic/parabolic/sharp/falt Bottons
High Light:

carbide button bits

,

retrac button bit

Description

Top Hammer Drill Bits mine drilling bit adopt high quality steel and tungsten carbide to ensure product quality. With superior wear resistance and impact toughness, our button drill bit is very popular at home and abroad.



1.Comparing with tapered chisel bits and tapered cross bits, button bits has higher technology, much longer primary drilling time and higher drilling efficiency, so that the button bit is popular among the users.

2.Tapered equipment affords drillers the ability to change drilling bits whilst still using the same drilling rod. Drillers choose tapered button bits for faster drilling penetration rate. Different taper sizes have different characteristics when it comes to the “knock-off” index – the smaller angle will prevent the bit from spinning.

3. Suitable for small hole range
• Widely used in Dimensional Stone Quarrying Industry
• Widely used in Underground Mining Industry



Comparing with tapered chisel bits and tapered cross bits, button bits has higher technology, much longer primary drilling time and higher drilling efficiency.



Applications


Widely used in mines, quarries, earthworks and other engineering drilling blasting hole, guardrail hole,mountain reinforcement, anchorage and other engineering holes, geothermal exploration hole, Well bore and other fields.



Specifications


Dia Tip size(mm) NO.flusging holes

Weight

(kg)

mm Gauge Front Side Front
70 6*12 4*10 0 2 2.4
76 6*13 4*10 0 2 2.6
89 8*12 5*12 2 2 4.5
102 8*13 6*12 2 2 5.0
115 8*14 6*13 2 2 6.8
64 6*10 4*9 0 3 1.6
70 6*12 4*10 0 3 2.4
76 8*11 5*10 0 4 2.6
89 8*12 6*12 0 4 4.6
102 8*13 6*12 0 4 4.5
70 8*11 4*10 2 2 2.5
76 8*11 4*10 2 2 3.1
80 8*12 5*11 2 2 4.0
89 8*12 5*12 2 2 5.1
102 8*13 6*12 2 2 8.2
70 8*10 5*9 0 4 2.2
76 8*11 5*10 0 4 3.1
89 8*12 6*12 0 4 5.4
102 8*13 6*12 0 4 7.8
105 8*13 6*12 0 4 8.3



Feature Advantage

Advantages:
Compared with the oversea brands, our advantages are bellowing:
a. Our products can match over 95% against the original products
b. Price are competitive against the famous brands and best quality against the small factory



About Us:
1. Our factory has been specialized in manufacturing drilling tools and spare parts for over 10 years.
2. We have advanced technology and equipment.
3. Our technician has more than 13 year’s professional working experience.
4. Rock drilling tools are exported throughout the world.



The appearance of the picture is different from that of the actual product, and the actual product is the standard.
