Professional T45 DTH Small Rock Drill Bits , Earthworks Tapered Button Bits

Professional T45 DTH Small Rock Drill Bits , Earthworks Tapered Button Bits

  • Professional T45 DTH Small Rock Drill Bits , Earthworks Tapered Button Bits
Professional T45 DTH Small Rock Drill Bits , Earthworks Tapered Button Bits
Product Details:
Place of Origin: Hunan, China (Mainland)
Brand Name: New Diamond
Certification: ISO9001:2008
Model Number: T45
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: Carton packaging and wooden box packing
Delivery Time: 5-8 work days
Payment Terms: L/C, T/T, Western Union
Supply Ability: According to order quantity
Contact Now
Detailed Product Description
Type: Drill Bit Use: Well Drilling
Bit Face: FF, DC, Concave, Convex Color: Required
Material: Alloy Steel Delivery Time: 3-5 Days For Sample
High Light:

top hammer drilling tool

,

carbide button bits

Description


Comparing with tapered chisel bits and tapered cross bits, button bits has higher technology, much longer primary drilling time and higher drilling efficiency.



According to the tungsten carbide insert, tapered button bits can be divided into the types of hemispherical, conical andparabolic button, etc.



Thread button drill bits are made by high quality alloy steel bar and tungsten carbides. Through heat treatment, our drilling tools are tough enough to meet rock drilling demands and have the least loss of energy while drilling the rocks. Besides, we can design customized thread button drill bits according to different drilling application, and custom drill bits are applicable to drill soft rock, loose-medium rock and hard rock.



Applications


Widely used in mines, quarries, earthworks and other engineering drilling blasting hole, guardrail hole,mountain reinforcement, anchorage and other engineering holes, geothermal exploration hole, Well bore and other fields.



Specifications


Dia Tip size(mm) NO.flusging holes

Weight

(kg)

mm Gauge Front Side Front
70 6*12 4*10 0 2 2.4
76 6*13 4*10 0 2 2.6
89 8*12 5*12 2 2 4.5
102 8*13 6*12 2 2 5.0
115 8*14 6*13 2 2 6.8
64 6*10 4*9 0 3 1.6
70 6*12 4*10 0 3 2.4
76 8*11 5*10 0 4 2.6
89 8*12 6*12 0 4 4.6
102 8*13 6*12 0 4 4.5
70 8*11 4*10 2 2 2.5
76 8*11 4*10 2 2 3.1
80 8*12 5*11 2 2 4.0
89 8*12 5*12 2 2 5.1
102 8*13 6*12 2 2 8.2
70 8*10 5*9 0 4 2.2
76 8*11 5*10 0 4 3.1
89 8*12 6*12 0 4 5.4
102 8*13 6*12 0 4 7.8
105 8*13 6*12 0 4 8.3


Feature Advantage


Advantages:
Compared with the oversea brands, our advantages are bellowing:
a. Our products can match over 95% against the original products
b. Price are competitive against the famous brands and best quality against the small factory



About Us:
1. Our factory has been specialized in manufacturing drilling tools and spare parts for over 10 years.
2. We have advanced technology and equipment.
3. Our technician has more than 13 year’s professional working experience.
4. Rock drilling tools are exported throughout the world.
