COP54 Concave Water Drill Bit For DTH Drilling Machine , ISO Standard

COP54 Concave Water Drill Bit For DTH Drilling Machine , ISO Standard

  • COP54 Concave Water Drill Bit For DTH Drilling Machine , ISO Standard
COP54 Concave Water Drill Bit For DTH Drilling Machine , ISO Standard
Product Details:
Place of Origin: Hunan, China (Mainland)
Brand Name: New Diamond
Certification: ISO9001:2008
Model Number: COP54
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: Carton packaging and wooden box packing
Delivery Time: 5-8 work days
Payment Terms: L/C, T/T, Western Union
Supply Ability: According to order quantity
Contact Now
Detailed Product Description
Type: Drill Bit Processing Type: Forging
Use: Ore Mining Color: Required
Usage: Quarrying& Ore Mining& Well Drilling Button Shape: Spherical/Ballistic/parabolic/sharp/falt Bottons
High Light:

hard rock drill bits

,

ballistic button bits

COP54 Concave Water Drill Bit For DTH Drilling Machine , ISO Standard



Description

Hunan New Diamond offers top quality DTH hammers and bits which have been tested in the hardest rock formation. Our bits use quality hardened steel alloy for the bit body and premium quality tungsten carbide buttons. With superb performance and long life span. Our bits won high reputation among our customers.



DTH Drill Bits:
1. Factory price.
2. High performance.

3.High quality raw materials.

4. OEM and OEM are available.

Using:
tungsten carbide button bit drilling series.

Suitable for cutting, drilling various hard Non-ferrous materials, such as marble, granite, glass, ceramic, hard concrete and brick.



Applications

It is mainly used in geological exploration, coal mine, water conservancy and hydropower, highway, railway, bridge, construction and so on.



Specifications


THE Drill Head Diameter(mm) Spline Key Number NO.Air Holes Gauge Buttons Front Buttons Weight(KG)
133 - 2 7XØ16 7XØ14 15.0
140 - 2 7XØ18 7XØ14 16.0
146 - 2 8XØ18 7XØ14 17.0
152 - 2 8XØ18 8XØ14 17.5
165 - 2 8XØ18 8XØ16 18.5
WE can design and manufacture according to customers requirement of the bit diameter,the NO.of air holes,carbide buttons and the face shape.

Feature Advantage

1. Long life span: the wear-resist of tungsten carbides is 10-20 times higher compared with other similar materials, which greatly extends the life of the carbide bits;
2. High drilling efficiency: the high grade hardness of the carbides can always stay sharp, which could increase the drilling speeds too;
3. Lower cost.

COP54 Concave Water Drill Bit For DTH Drilling Machine , ISO Standard 0

COP54 Concave Water Drill Bit For DTH Drilling Machine , ISO Standard 1
