Hunan New Diamond Construction Machinery Co., Ltd.
 |
| Place of Origin: | Hunan, China (Mainland) |
| Brand Name: | New Diamond |
| Certification: | ISO9001:2008 |
| Model Number: | HD25A |
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Carton packaging and wooden box packing |
| Delivery Time: | 5-8 work days |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | According to order quantity |
| Tail Length (without Head): | 174mm | Processing Type: | Forging |
|---|---|---|---|
| THE Drill Head Diameter(mm): | 76-90mm | Spline Key Number: | 6 |
| Bit Face: | Center Drop/Flat/convex/concave/double Gauge Face Bits | NO.Air Holes: | 2 |
| High Light: | threaded button bits,button drill bit |
||
Description
New diamond dive drill percussion features:
1. The latest rock drilling theory is used to design the internal structure size of the impactor, which makes the impactor get the best energy transfer, the rock drilling speed is fast, and the air consumption is low.
2, the use of high-quality raw materials and advanced processing technology, stable performance and long life.
3, the simple and reliable internal structure is easy to install and disassemble.
Specifications
| DHD | Head shape |
Diameter (mm) |
Number of vents | NO X button diamter | weight (KG) | ||
| Toothed | Gauge | Front | |||||
| HD25A | Flat Face Bit | 76 | 2 | Ballistic Button | 6XØ14 | 4XØ11 | - |
| Flat Face Bit | 80 | 2 | Ballistic Button | 6XØ13 | 4XØ11 | - | |
| Flat Face Bit | 90 | 2 | Ballistic Button | 6XØ14 | 4XØ12 | - | |
| We can design and manufacture according to customers requirement of the bit diameter,the NO.of air holes,carbide buttons and the face shape. | |||||||
1. Long life span: the wear-resist of tungsten carbides is 10-20 times higher compared with other similar materials, which greatly extends the life of the carbide bits;
2. High drilling efficiency: the high grade hardness of the carbides can always stay sharp, which could increase the drilling speeds too;
3. New Diamond's bits are widely used in different rock formations like carbonate rock,limestone,chalk rock, clay rock,siltstone and sandstone;
4. It can greatly reduce the drilling cost, because of its high drilling speed and life span, which reduces the times to changes bits in the drilling service.
DTH Drill Bits:
1, Direct sale
2, reasonable price
3. high efficiency
Using:
tungsten carbide button bit drilling series
Suitable for cutting, drilling various hard Non-ferrous materials, such as marble, granite, glass, ceramic, hard concrete and brick.
Applications
It is mainly used in geological exploration, coal mine, water conservancy and hydropower, highway, railway, bridge, construction and so on.
The appearance of the picture is different from that of the actual product, and the actual product is the standard.
