High Reliability Reverse Circulation Hammer Alloy Steel For Earthwork Project

High Reliability Reverse Circulation Hammer Alloy Steel For Earthwork Project

  • High Reliability Reverse Circulation Hammer Alloy Steel For Earthwork Project
High Reliability Reverse Circulation Hammer Alloy Steel For Earthwork Project
Product Details:
Place of Origin: Hunan, China (Mainland)
Brand Name: New Diamond
Certification: ISO9001:2008
Model Number: Reverse Circulation Hammer
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: Carton packaging and wooden box packing
Delivery Time: 5-8 work days
Payment Terms: L/C, T/T, Western Union
Supply Ability: According to order quantity
Contact Now
Detailed Product Description
Type: Hammer Processing Type: Forging
Use: Ore Mining Color: Required
Machine Type: Drilling Equipment Material: Alloy Steel
High Light:

rock quarry tools

,

rock drill accessories

Description


Down the hole rock tools (drilling tools) are rock drilling equipment which takes compressed air as power source to partially transfer impact power into drilling holes. An air distributing device in a top hammer controls a piston to move back and forth. An impact device arranged in the front of the top hammer transfers the impact powderto a down-the-hole bit to crush rocks.

1. Based on previous experience of ordinary hammers, combined with the features of reverse circulation hammer, optimized internal structure and ideal energy transfer, thus ensuring the series of hammers drilling with fast, smooth and continuous sampling.



2. The internal structure is very simple with components of high rigidity, thus ensuring long life and easy maintenance of the hammer.



3. The collection tube adopts an integrative design and can be replaced without disassembling the hammer. With carburizing treatment, it has good abrasive resistance.



4. Equipped with bits designed with patent. Simply by replacing the drill bit, the same hammer
can drill holes of different sizes ensuring that the sample is not contaminated.



5. In difficult conditions such as loose soil, hard rock and plenty of water exists, sampling can be done well.


Applications


Our DTH hammer are widely applied to open pit and underground mining to drill blasting holes, drainage holes, ventilation holes, center holes or blasting holes of raising boring, pipe holes and other deep holesin all various strength rocks, such as quarry exploitation, earthwork projects, water-well, constructionsand so on.



Specifications






Item Description Weight(kg)
NRC45 NRC55 NRC65 NRC52
Internal Ciclip 0.03 0.04 0.05 0.04
Air Screen 0.35 0.44 0.65 0.44
Top Sub 6.50 9.65 20.00 9.65
“O”Ring 0.01 0.02 0.02 0.02
Sample Tube 5.10 6.72 12.50 6.75
Check Valve 0.25 0.68 0.85 0.68
Spring 0.04 0.12 0.10 0.12
“O”Ring 0.01 0.02 0.02 0.02
Air Distributor 0.85 1.48 3.50 1.48
10,“O”Ring 0.02 0.01 0.02 0.01
Internal Cylinder 2.20 4.12 4.20 4.12
Piston 8.50 16.90 24.00 16.90
External Cylinder 14.50 19.50 32.00 21.50
Guided Sleeve 1.20 0.90 5.50 1.90
“O”Ring - - - 0.02
Stop “O”Ring - - - 0.01
Stop Ring - - - 0.32
Sharout - - - 1.86
Drive Chuck 3.20 5.65 6.50 4.17
Bit Retaining Pin 0.01 0.15 0.30 -
Drill Bit 10.50 15.80 31.00 11.05


Feature Advantage


1. Price commitment: in order to ensure the high reliability of products, raw material selection are using grapefruit brand products; under the same competitive conditions,and not to reduce product technical performance on the basis of sincerity at a favorable price to customers.


2. Quality commitment: product manufacturing and testing have quality records and inspection data; the performance of the product can withstand customer inspection.



3. Customer service: in order to create new diamond brand, enhance the visibility of enterprises, establish corporate image, we serve customers with the principle of "preferential prices, good service, reliable product quality" principle.
