10 Inch Down The Hole Hammer For High Working Air Pressure NSD10 Series

10 Inch Down The Hole Hammer For High Working Air Pressure NSD10 Series

  • 10 Inch Down The Hole Hammer For High Working Air Pressure NSD10 Series
10 Inch Down The Hole Hammer For High Working Air Pressure NSD10 Series
Product Details:
Place of Origin: Hunan, China (Mainland)
Brand Name: New Diamond
Certification: ISO9001:2008
Model Number: NSD10
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: Carton packaging and wooden box packing
Delivery Time: 5-8 work days
Payment Terms: L/C, T/T, Western Union
Supply Ability: According to order quantity
Contact Now
Detailed Product Description
Type: Hammers Processing Type: Forging
Use: Ore Mining Color: Required
Key Word: DTH Hammer Application: MARBLE QUARRY OR WELL DRILLING
High Light:

dth hammer

,

oil drilling tools

Description


1. according to China's mining conditions, to absorb the advanced technology of domestic and foreign impactor and design and manufacture of the latest products.


2. reasonable selection of materials, advanced manufacturing technology, quality assurance perfect.


3. has higher drilling speed.


4. can provide hardening treatment in order to prolong the service life and reduce the cost of use.


5. single impact power is large, and the power consumption of broken rock is low.


6. piston and bit weight to have the best momentum transfer.


7. the modern theory is adopted in the structural design, which makes the stress wave duration longer, the stress amplitude is lower, and the piston life is long.



Applications


     It is mainly used in geological exploration, coal mine, water conservancy and hydropower, highway, railway, bridge, construction and so on.



Specifications


Technical Data
Length(Without Bit) NSD10
1502mm
Weight(Without Bit) 290.00kg
External Diameter Ø226mm
Bit Shank SD10
Hole Range Ø254-Ø311mm
Connection Thread

API4 1”/2REG

API6 5”/8REG

Working Pressure 2.0-3.5Mpa
Impact Rate at 17 Bar 18HZ
Recommended Rotation Speed 20-30r/min
Air Consumption

1.0Mpa:22.0m³/min

1.8Mpa:40.0m³/min

2.4Mpa:55.0m³/min





Feature Advantage


1. Price commitment: in order to ensure the high reliability of products, raw material selection are using grapefruit brand products; under the same competitive conditions, and not to reduce product technical performance on the basis of sincerity at a favorable price to customers.



2. Quality commitment: product manufacturing and testing have quality records and inspection data; the performance of the product can withstand customer inspection.



3. Customer service: in order to create new diamond brand, enhance the visibility of enterprises,establish corporate image, we serve customers with the principle of "preferential prices, good service, reliable product quality" principle.
